M18™ 120’ Pipeline Inspection System

Our M18™ 120’ Pipeline Inspection System delivers the clearest image, easiest inspections for 2"-6” sewer lines up to 120’. Featuring the industry’s shortest 25 mm 1080p self-leveling HD camera head, and the ability to digitally zoom up to 4X and pan, technicians can now see more in drain lines than ever before. With the system’s compact design and removable backpack straps, transportation to any roof or cleanout has never been easier. Powered by M18™ REDLITHIUM™ 5.0 batteries, the M18™ 500GB Control Hub powers the reels, stores recordings, and easily swaps between reel sizes delivering unmatched system versatility. Capture, create, and share custom photos and videos from the M18™ Wireless Monitor or directly from a tablet or mobile device for faster sharing of findings. This sewer line camera is also equipped with ONE-KEY™ Technology, providing you with the ability to track the tool's location, manage it in inventory, and lock the tool out to help protect your investment. Our M18™ 120’ Pipeline Inspection System includes (1) 120' Pipeline Inspection Reel, (1) M18™ 500 GB Control Hub, (2) M18™ XC 5.0 Batteries, (1) M18™ & M12™ Rapid Charger, (1) Tablet Mount, (1) small camera head skid for 25 mm camera, (1) medium camera head skid for 25 mm camera head, (1) Grounding stake with lead clamps and cable.

M18™ 120’ PIPELINE
INSPECTION SYSTEM

CLEAREST IMAGE.
EASIEST INSPECTIONS.

HD CAMERA DELIVERS 4X DIGITAL ZOOM

  • 25 mm Self-Leveling Camera Head
  • Highest Resolution during live streaming, picture, and video

CAPTURE, CREATE AND SHARE TO MOBILE DEVICES

  • Save HD images and video recordings to M18™ 500 GB Control Hub
  • Send saved recordings faster directly from mobile device

MONITOR MOUNT AND BACKPACK STRAPS FOR HANDS-FREE CARRYING

  • Adjustable Monitor Mount for best viewing
  • Removable backpack straps provide best transportation when accessing roofs

KEY FEATURES - M18™ 120’ Pipeline Inspection System (2973-20)

  • 1080p camera resolution providing the industry's clearest image inside of drain lines
  • 25 mm self-leveling HD camera head
  • 10 mm Push Cable Diameter provides best mix of stiffness and flexibility
  • Powered by the M18™ 500GB Control Hub
  • Removable backpack straps for hands free carrying
  • On board monitor mount for viewing and transportation
  • Swap batteries without system shutdown

KEY FEATURES - M18™ 500GB CONTROL HUB (2970-20)

  • Record, Edit & Share to Mobile Devices
  • Swap Batteries without System Shutdown
  • Unmatched Versatility, Control Hub Swaps Between Reels
  • Up to 200' of Wireless or wired connectivity to viewing device
  • On board USB port allows for saving findings on memory stick
  • One-Key™ technology allows for tracking, tool security, and inventory management
  • Up to 9 hours of runtime with an M18™ REDLITHIUM™ 5.0AH Battery
  • Wired connection backup to the M18™ Wireless Monitor via USB-C port
  • Water tight battery door protects against water and debris
  • Integrated handle and latch allow for easy one handed installation
  • Sealed Battery Door
  • Sealed USB Door
You May Also Like...

Battery Specifications

Voltage 18V

Product Specifications

Tool Warranty 5 Year
Line Capacity 2"-6"
Push cable length 120'
Push Cable Diameter 10mm
Camera resolution 1080p
Camera head Ingress Protection IP67
Sonde Frequency 512 Hz, 33 kHz
Line Trace Frequency 33 kHz, 83 kHz
Camera Head Warranty 1 Year


Product Specifications

Tool Warranty 5 Year
Battery Type M18
Length 12.2"
Video Display M18™ Wireless Monitor or Milwaukee® Pipeline Inspection App
Wireless Range 200 Feet
Runtime 9 hours
Photo Format JPEG
Video Format MPEG4
Internal Storage 500GB
Data Transfer Method USB, wireless to mobile devices
Line Trace Frequency 33 kHz, 83kHz
